Application:
this cutting machine is very suitable for die cutting leather materials, such as leather bag, leather cases, leather seats, leather wallets, leather logo and so on.
Feature:
1.With low stroke of 50-160mm to cut leather sheet, saving time and easy to cut.
2.With 558x1600mm of large cutting area, suitable for leather, and interiors in purse.
3.Available for material sheet and rolls.
4.Sliding table easy to operate.
5.Hydraulic system along with auto-balance structure, to keep cutting process more pricision, and low noise.
6. Small tons 25 tons is suitable
Optional to feed
PLC control system
Feeding roller
Feeding longer table
Optional parts
Motor: Siemens
Oil pump: Japanese Yuken(PV2R2-47-1R)
Hydraulic system: Taiwan JeouGang
Electromagnetic valve seat：Taiwan
Seals: Germany SHAMBAN
Main electric: Japanese Fuji and Japanese Omron
Button: Japanese Fuji.
Cutting force
25T
Cutting area
558x1600mm
Cutting Plate
558x1600mm
Motor
2.2kw
Stroke
50-240mm
Voltage
3 phase 220/380/415/440V 50/60HZ
Net weight
1600kg
Gross weight
1650kg
Dimension
1950x1320x1260mm
CBM
small leather goods:
purse,
toys,
phone case,
wine packaging,
Key chain,
Key fobs, Spectacle cases
Wallets
