| Cutting force |
50T,60T,80T,100T,120T,150T,180T,200T, 300T |
| Cutting area |
1400x810mm, 1400x710mm, 1600x810mm as request. |
| Motor |
4kw,5.5kw,7.5kw,9.5kw,11kw |
| Stroke |
max 180mm |
| Feeding type |
Semi-auto feeding, by pressing the buttons to feed the feeding table |
| Open |
50-230mm |
| Control system |
Fatek PLC controlled |
| Table feeding speed |
Adjustment |
| Working tables |
single table, double tables |
| Voltage |
3 phase 220/380/415/440V 50/60HZ |
| Net weight |
3000-100000kgs |
| Feeding materials |
Sheets, with limit in feeding length |
| Cutting Thickness |
0.1mm-90mm |
| Die Setting |
In touch screen, auto setting |
| Cooling |
Fan, water recycle |
| Cutting Head Height |
Adjustment |
| Color |
Blue standard, or as request |
| Counting |
Auto counting |
