F20T fabric grinding cloth Die Cutting Press Machine

Model:HG-F20T

This item has added to inquiry basket
Enter Inquiry Cart now.

This item was already in your inquiry basket
Please Check your Inquiry Cart .

Cutting force	15T, 20T, 30T
Cutting area	500x500mm, 610x1220mm, 610x1600mm,etc as request.
Cutting Plate	500x500mm,610x1220mm, 610x1600mm,etc as request.
Model	HG-A30T,A40T,A50T, HG-B30T,B40T, B50T
Pressure Adjustment	Yes
Feeding type	By hand to drag or push the wood feeding table
Feeding materials	No limits
Cutting Thickness	0.1mm-90mm
Counting	Auto counting
Cooling	No
Motor	2.2kw,4kw
Stroke	50-240mm,50-160mm,50-230mm
Voltage	3 phase 220/380/415/440V 50/60HZ
Net weight	1900kg-2800kg
Dimension	2330x1320x1260mm,1950x1320x1260mm
CBM	4.26cbm, 3.8cbm
